5041-030
Change history
Revision date Updates
2013/12/16 Removed the Reset color calibration topic from the Diagnostic information chapter.
2013/07/01 Added Steps before starting the 9yy.xx service checks.
2012/06/25 • Added “Safety feature notice” on page 2-1.
• Updated and changed the Abnormal fuser temperature error service check to “ON /
OFF switch automatically switching to the Off position service check” on
page 2-59.
2012/01/10 Added the units/mach for the transfer roll bushing and duplex carrying gear under “Duplex
components 1” on page 7-7.
2011/12/14 Added an installation note in the “Waste toner sensor removal” on page 4-88.
2011/12/01 • Added a note in the “Paper feed unit removal” on page 4-58.
• Added the following removal procedures:
- “Main tray paper guide removal” on page 4-95.
- “Multi-purpose feed tray paper guide removal” on page 4-97.
• Updated the parts catalog art for “Paperfeed” on page 7-18.
2011/11/22 Updated the “Printhead controller board / engine board replacement” on page 4-2.
2011/10/04 • Changed PN 40X6424 with PN 40X5984 for the “Low voltage power supply (220V)”
on page 7-21.
• Added Change history section
• Added the navigation buttons
2011/08/09 • Added the following menu items under “Configuration Menu” on page 3-7
- “Reset Separator Roll and Pick Assembly Counter” on page 3-8
- “Fuser Speed” on page 3-9
- “Wipe All Settings” on page 3-12
- “USB PnP” on page 3-13
- “Automatically Display Error Screens” on page 3-13
• Changed all references to Wipe Disk to “Erase all information on Disks” on
page 3-12.
• Removed the following menu item definitions:
- * Color Adjustment
- * Color Adj State
- * Motor Calibration
2011/08/03 Updated the following removal procedures under Chapter 4:Repair information
- “Duplex removal” on page 4-53
- “Paper feed unit removal” on page 4-58
2011/05/05 Added the “Top EMI sheild removal” on page 4-30.
