Lexmark C925 - 24 X Paper Jam

To Next Page

To Previous Page

Diagnostic information 2-17

5041-030

Go Back

24x paper jam

Jam in tray 1

1. Open the right cover, and pull any jammed pages out.

2. Open Tray 1, and pull the jammed pages up and out.

3. Close Tray 1.

4. Press Continue, jam cleared.
