False close door service check
Operator panel service check
Step Action and questions Yes No
1 Open and close the right cover. Does the message
reset?
Problem solved Go to step 2.
2
Check the right door release lever. Does it operate
smoothly, and is the interlock actuator intact?
Go to step 3. Replace the
faulty part on the
door.
3
Is the interlock switch cable properly connected to the
interlock switch and CN23 on the engine board?
Go to step 4. Properly connect
the interlock
switch cable.
4
Replace the interlock switch. Did this fix the problem? Problem solved. Go to step 5.
5
Replace the engine board. Did this fix the problem? Problem solved. Contact your
second level
support.
Step Action and questions Yes No
1 Are the LEDs on the operator panel and display
illuminating?
Go to step 2. Go to step 3.
2
Perform button test in the diagnostics menu. Did the
tests work?
Problem solved. Go to step 3
3
Check the cable connections on the UICC,
touchscreen and RIP board. Are they connected?
Go to step 5. Go to step 4.
4
Reconnect the cables. Did this fix the issue Problem solved Go to step 5
5
Reseat the video board to the RIP board. Did this fix
the issue?
Problem solved. Go to step 6.
6
Check the cables for continuity. Is there continuity? Go to step 8. Go to step 7.
7
Replace the cables. Did this fix the issue? Problem solved Go to step 8.
8
Replace the UICC. Did this fix the issue? Problem solved. Go to step 9.
9
If the display is not working, replace the display. Did
this fix the issue?
Problem solved. Go to step 10.
10
Replace the video board. Did this fix the issue? Problem solved. Go to step 11.
11
Replace the RIP. Did this fix the issue? Problem solved. Contact your
second level
support.
