Lexmark C925 - Connector Values

Locations 5-13
5041-030
Go Back
Previous
Next
Connector values
RIP / video boards
Connector Connects to Pin no. Signal
Video board connectors
JBOOT1 1 +3.3V
2 IM_DATA (7:0)
J105 1 UI_RESET_NR
2GND
3CON_TX1-
4CON_TX1+
5CON_TX2-
6CON_TX2+
7CON_CLKTX-
8CON_CLKTX+
9GND
10
11 I2C_CLK_UI
12 I2C_DATA_UI
13 CON_TX0-
14 CON_TX0+
15 GND
16 +5V
17 +5V
18 V_UI
19 WAKE
20 GND
21 GND
22 LED_DRV_YELLEOW
23 +5V_CONT
24 PWR_BUTTON
J4
J101 1 +5V
2 USB_FRONT_P1+
3 USB_FRONT_P1-
4GND
