Parts catalog 7-5

5041-030

Go Back

Assembly 2: Cover 2

Asm-

index

Part

number

Units/

mach

Units/

FRU

Description

1 40X6379 1 1 Button kit parts pack

2 40X7115 1 1 UICC (user interface controller) card

3 40X6405 1 1 RIP - USB Cable

4 40X6431 1 1 RIP-Operator panel cable

5 40X7116 1 1 4.3” Touchscreen display

6 40X6284 1 1 Op panel bezel cover

7 40X6378 1 1 Upper op panel cover

NS 40X6549 1 1 USB - UICC Cable

NS 40X6873 1 1 Cover 2 screw parts pack
