Parts catalog 7-13

5041-030

Go Back

Assembly 6: Base 1

Asm-

index

Part

number

Units/

mach

Units/

FRU

Description

1 40X6173 1 1 Main unit drive

2 40X6261 1 1 Photo interrupter cable

3 40X1104 8 1 Photo interrupter

4 40X6160 1 1 Sub frame

5 40X6162 1 1 Belt motor

6 40X6262 1 1 Belt motor cable

7 40X6161 4 1 Drive unit motor

NS 40X7052 1 1 Base 1 screw parts pack
