Parts catalog 7-23
5041-030
Assembly 11: Electrical 2
Asm-
index
Part
number
Units/
mach
Units/
FRU
Description
1 40X6196 1 1 Engine board
2 40X6368 1 1 Engine power supply cable
3 40X6210 1 1 Power supply fan cable
4 40X6262 1 1 Belt motor cable
5 40X6206 1 1 Main fan cable (fan included)
6 40X6203 1 1 Humidity sensor cable
7 40X6120 1 1 Paper size sensor cable
8 40X6427 1 1 Engine board fan cable (fan included)
9 40X6419 1 1 MPF clutch
10 40X6416 1 1 MPF-Engine board cable
11 40X6190 1 1 Registration sensor cable
12 40X6207 1 1 RIP Harness cable
13 40X6261 1 1 Photo interuptor cable (Belt up/down)
14 40X6194 1 1 Paperfeed clutch cable
15 40X6165 1 1 Exit solenoid cable (w/solenoid)
16 40X6209 1 1 Tray lift motor cable
17 40X6171 1 1 Fuser fan cable (fan included)
18 40X6367 1 1 Engine paperfeed cable
19 40X6161 1 1 Drive unit motor (w/motor)
NS 40X7454 1 1 Remote off switch cable
NS 40X7455 1 1 Cover closed actuator cable
NS 40X7456 1 1 Paper tray size switch cable
NS 40X7448 1 1 Electrical screw parts pack
To Next Page
