Parts catalog 7-27

5041-030

Go Back

Assembly 13: Printer controller board cables

Asm-

index

Part

number

Units/

mach

Units/

FRU

Description

1 40X6193 1 1 Registration sensor cable

2 40X6211 1 1 Fuser power cable (110V)

2 40X6440 1 1 Fuser power cable (220V)

3 40X6168 1 1 Paper exit sensor cable

4 40X6278 1 1 Fuser exit sensor cable

5 40X6217 1 1 Printhead controller board

6 40X6201 1 1 Density sensor cable

7 40X6198 1 1 Theta sensor cable

8 40X6210 1 1 Power supply fan cable

9 40X6370 1 1 RIP print controller cable

10 40X6369 1 1 Printhead controller option cable

11 40X6207 1 1 RIP harness cable
