Lexmark C925 - Page 337

To Next Page

To Previous Page

Parts catalog 7-29

5041-030

Go Back

Assembly 14: Paper trays

Asm-

index

Part

number

Units/

mach

Units/

FRU

Description

1 40X6223 1 1 Multipurpose tray

2 40X6219 1 1 Main paper tray

NS 40X6220 1 1 Tray rack gear

NS 40X6221 1 1 Tray pinion gear

NS 40X7451 1 1 Cassette screw parts pack
