Lexmark C925 - Page 341

To Next Page

To Previous Page

Parts catalog 7-33

5041-030

Go Back

Assembly 16: 550 sheet option feeder covers

Asm-

index

Part

number

Units/

mach

Units/

FRU

Description

1 40X6357 1 1 Right option tray cover

2 40X6227 1 1 Drive roller

3 40X6251 1 1 Right front option cover

4 40X6252 1 1 Right rear option cover

5 40X6254 1 1 Right switch cover

6 40X6224 1 1 Stand base foot

7 40X6250 1 1 Left option cover

8 40X6248 1 1 Rear option cover

9 40X6249 1 1 Rear connector cover

10 40X6255 1 1 Upper front option cover

11 40X6253 1 1 Right middle option cover

NS 40X1173 1 1 Horizontal sensor (paper level)

NS 40X7452 1 1 550 sheet paperfeed screw parts pack
