Lexmark W850 - Punch Waste Box Full

Diagnostic information 2-93
4024-XXX
Punch waste box full
4 Perform a test print.
Does the error still occur?
Replace the
bridge interface
card assembly.
Go to “Bridge
unit interface
card assembly
removal” on
page 4-117.
Go to step 5.
Problem solved.
5 Perform a test print.
Does the error still occur?
Replace the
finisher controller
card assembly.
Go to “Finisher
controller card
assembly
removal” on
page 4-118.
Problem solved.
Step Check Yes No
1 Check the sensor (punch waste box full) for correct
installation.
Is the sensor installed properly?
Go to step 2. Reinstall the
sensor (punch
waste box full).
Go to “Sensor
(punch waste
box full)
removal” on
page 4-53.
2 Check the sensor (punch waste box full).
Perform the sensor (punch waste box full) test.
1. Enter Diagnostics mode.
2. Select FINISHER TESTS.
3. Select Sensor Tests.
4. Select Punch and Staple.
5. Select Punch waste box full.
Open the finisher front door.
Remove the punch waste box.
Insert a sheet of white media into the sensor (punch
waste box)
Does the display on the operator panel change every
time the sensing area of the sensor (punch waste box
full) is blocked?
Go to step 4. Go to step 3.
3 Perform a test print.
Does the error still occur?
Replace the
sensor (punch
waste box full).
Go to “Sensor
(punch waste
box full)
removal” on
page 4-53.
Replace the
connection.
Step Check Yes No
