Lexmark W850 - Rear Upper Cover Removal

4-24 Finisher Service Manual
4024-XXX
Rear upper cover removal
1. Release the hook of the bridge unit hookup cover (A) to the finisher.
2. Disconnect the bridge unit harness from the finisher.
3. Remove the four screws securing the rear upper cover (B) to the finisher.
4. Remove the rear upper cover (B).
A
B
Hook
