Lexmark W850 - Understanding Printer Messages

3-18 Finisher Service Manual
4024-XXX
Rear tamping
Rear tamping is used in the following cases.
• When executing rear stapling (corner)
• When executing dual stapling
The tamper positions during rear tamping are shown below.
Position Description
1 Front tamper home position—sensor (front tamper HP)
2 Front tamper tamping position
3 Front tamper offset position
4 Rear tamper home position—sensor (rear tamper HP)
5 Rear tamper size position
6 Rear tamper offset position
Sensor (front tamper HP)
Front
Sensor (rear tamper HP)
Rear
Front tamper motor Front tamper
Rear tamper motor
Rear tamper
