Lexmark W850 - Right Eject Cover Removal

Repair information 4-21
4024-XXX
Right eject cover removal
1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27.
2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24.
3. Remove the two screws securing the right eject cover (A) to the finisher.
4. Remove the right eject cover (A).
A
Right
