Diagnostic information 2-79
7541-03x
14 Press **411 to enter the Fax/SE Menu.
Select “Print Logs”.
Print the T30 transmission log. Check the
error being reported with the fax error code
table. See
“Fax T30 log error codes” on
page 2-41. Perform the suggested
resolution for the error.
Did this fix the problem?
Problem resolved. Go to step 15.
15 Adjust the “Transmit Level” setting in the SE
menu. Press **411 to enter the SE menu,
enter Modem settings, and select “Transmit
Level”.
Test by adjusting the transmitted signal
strength by decreasing/increasing the
‘Transmit Level’ setting in steps of 1db. For
example, if default value is -11 db, changing
it to -12db will decrease the signal strength
by 1db, and changing it to -10db will
increase the signal strength by 1db.
Recommended adjustment range is ±5 db
(in 1db steps) from the default value.
Did this fix the problem?
Stop. Problem
resolved.
Go to your second-
level of support. See
“Escalating a fax
issue to second-level
support” on
page 2-82.
Step Questions / actions Yes No
