1-2 Service Manual
7541-03x
Printer configurations
.
1 ADF input
2 ADF output bin
3 MPF feeder
4 550 sheet option tray (tray 3, 4, 5)
5 Caster unit
6 Storage cabinet
7 Standard 250-sheet tray (tray 1)
8 MPF 250-sheet tray (tray 2
9 Output bin
10 10” touchscreen display
*
The printer supports up to three 550-sheet trays.
CAUTION—TIPPING HAZARD
Floor-mounted configurations require additional furniture for stability. You must use either a
printer stand or printer base if you are using a high-capacity input tray, a duplex unit and an
input option, or more than one input option. If you purchased a multifunction printer (MFP) that
scans, copies, and faxes, you may need additional furniture. For more information, see
www.lexmark.com/multifunctionprinters.
4
5
6
1
2
3
7
8
9
10
