5-26 Service Manual

7541-03x

Scanner ICC board connectors

ICC board

Connector Pin no. Signal

J1 FB Cover open 1 FB_COVER_OPEN

2 DGND

3 5V

J2 FB paper size sensor 2 1 GND

2 5V

3 FBPS2 3

4 FBPS2 2

5 FBPS2 1

J3 1 GND

2 24V_RIP

3 24V_RIP

4 24V_RIP

5 GND

6 TOP_FB

7 BOOT SEL

8 5V

9 5V

10 GND

11 MDC RXD

13 GND

14 ADF_PAPER_INMDC_TXD

15 F_COVER_OPEN

16 GND

17 HMSEN

18 PAPER_GAP

19 GND

20 RESET_N

21 3.3V

22 GND

23 HW RESERVE

24 IC2_CLK

25 IC2 DATA

26 GND
