Lexmark X925 - Paper Present; Paper in Sensor

4-144 Service Manual
7541-03x
Paper present / paper in sensor
Note: The ADF paper in and ADF paper present sensors are one assembly.
1. Remove the ADF outer cover.
2. Disconnect the sensor assembly (A) cable from the main cover sensor cable.
3. Remove the screw (B) holding the cable to the ADF inner cover.
4. Remove the screw (C) securing the ADF paper in sensor to the ADF inner cover.
5. Remove the screw (D) securing the paper present sensor to the ADF inner cover.
B
C
D
