4-106 Service Manual

7541-03x

4. Depress the tabs holding the sensor in place.

Rear EMI shield – Not a FRU

1. Remove the rear cover. See “Rear cover” on page 4-7.

2. Remove the RIP cage. See “RIP cage removal” on page 4-95.

3. Remove the cross bar. See “Crossbar removal (not a FRU)” on page 4-74.

4. Remove the two silver screws (A) securing the top rear of the EMI shield to the frame.
