Lexmark X925 - Page 220

4-38 Service Manual
7541-03x
4. Remove the screws (A) securing the cable box to the scanner support.
5. Remove the screw (B) securing the cable box to the top shield.
6. Remove the screws securing the top shield.
7. Disconnect all the cables from printhead controller board.
Warning: Be careful to avoid damaging the ribbon cables when removing them from the printhead
controller board.
A
B
