Lexmark X925 - Page 397

Locations 5-9
7541-03x
15 LEVELM-O0
16 LEVELM-O1
17 LEVELM-E0
18 LEVELM-E1
19 LEVELC-O0
20 LEVELC-O1
21 LEVELC-E0
22 LEVELC-E1
23 LEVELK-O0
24 LEVELK-O1
25 LEVELK-E0
26 LEVELK-E1
27 FEED2
28 SBSY
29 GND (RESRT
30 STATUS
31 FDRDY
32 CPRDY
33 STCLK
34 START
35 CBSY
36 PPRDY
37 STCLK
38 READY
39 COMMAND
40 GND
J12 Printhead controller board 1 VCLK_M
2 GND
3 VCLK_Y
4 GND
5 VCLK_C
6 GND
7 VCLK_L
8 GND
RIP board
Connector Pin no. Signal
