Locations 5-11

7541-03x

Printhead controller board

Connector Connects to Pin no. Signal

CN1 Yellow printhead 1 HD5V

2GND

3 HD5V

4GND

5 HD5V

6GND

7 HD5V

8GND

9 HD5V

10 GND

11 HD3V

12 SO-Y

13 SCK-Y

14 STROBE-Y

15 DATA_Y0

16 DATA_Y1

171 DATA_Y2

18 DATA_Y3

19 HSYNC-Y

20 LOAD_Y

21 GND

22 CLOCK-N-Y

23 CLOCK-P-Y

24 GND
