Lexmark X925 - Page 401

Locations 5-13
7541-03x
CN3 Magenta printhead 1 USB +5 V dc
2 USB D-
1 HD5V
2GND
3 HD5V
4GND
5 HD5V
6GND
7 HD5V
8GND
9 HD5V
10 GND
11 HD3V
12 SO-M
13 SCK-M
14 STROBE-M
15 DATA_M0
16 DATA_M1
171 DATA_M2
18 DATA_M3
19 HSYNC-M
20 LOAD_M
21 GND
22 CLOCK-N-M
23 CLOCK-P-M
24 GND
Printhead controller board
Connector Connects to Pin no. Signal
