Lexmark X925 - Page 412

To Next Page

To Previous Page

5-24 Service Manual

7541-03x

LVPS Connectors

LVPS board

Connector Connects to Pin no. Signal

CN01 Scanner power supply 1 AC-L

3AC-N

CN02 Fuser sensor 1 COM

2HT3

3HT2

4HT1
