Lexmark X925 - Page 418

5-30 Service Manual
7541-03x
J9 - CCD 30 pin 1 GND
2 LAMP_ON
3 24V_IN
4 24V_IN
5 GND
6 5V_CCD_IN
7 5V_CCD_IN
8 PWR_SVR
9 98714_SH_R
10 98714_SEN_N
11 98714_SCLK
12 98714_SDATA
13 GND
14 AFE_RESET
15 GND
16 98714_OUT0_P
17 98714_OUT0_M
18 GND
19 98714_OUT1_P
20 98714_OUT1_M
21 GND
22 98714_OUT2_P
23 98714_OUT2_M
24 GND
25 98714_CLK_P
26 98714_CLK_M
27 GND
28 INCLK_P
29 INCLK+M
30 GND
J10 FB paper size sensor 3 1 GND
2 5V
3 FBPS3 3
4 FBPS3 2
5 FBPS3 1
ICC board
Connector Pin no. Signal
