Parts catalog 7-9
7541-03x
Assembly 4: ADF 1
Asm-
index
Part
number
Units/
mach
Units/
FRU
Description
1 40X6338 1 1 ADF input tray
2 40X6966 1 1 Tray paper size sensors
3 40X6979 1 1 ADF tray bottom cover
4 40X6345 1 1 ADF paper stop
5 40X6346 1 1 Upper flatbed top cover
6 40X6344 1 1 Right ADF cover
7 40X6334 1 1 Flatbed hinge
8 40X6347 1 1 Lower flatbed top cover
9 40X6432 1 1 Flatbed cushion
10 40X6333 1 1 ADF hinge
11 40X6329 1 1 ADF relay card
12 40X6433 1 1 ADF cable
13 40X6342 1 1 ADF relay card cover
14 40X6343 1 1 Left ADF cover
15 40X6542 1 1 Release arm
16 40X6544 1 1 Idle clutch roller
17 40X6543 1 1 Idle pulley roller
NS 40X5867 1 1 ADF screws and fasteners parts pack
