Column Field Example Description
A SNVT 39 A numeric value of the SNVT (as defined in the SNVT
master list). The example value 39 represents a
SNVT_temp.
B NV index 0 The NV index in decimal of the NV on the network
node. Indices start at 0.
C NV selector 1 The NV selector in decimal of the NV on the network
node.
D NV name nvoTemp The NV programmatic name of the NV on the network
node.
E is output 1 Defines if this NV is an output on the network node. ‘1’
means the NV is an output on the network node.
F flag auth cfg 1 ‘1’ defines that authentication can be configured for this
NV on the network node.
G flag auth 0 ‘1’ defines that the NV is authenticated.
H flag priority cfg 1 ‘1’ defines that the priority can be configured for this
NV on the network node.
I flag priority 0 ‘1’ defines that the NV is using priority.
J flag servicetype
cfg
1 ‘1’ defines that the service type can be configured for
this NV on the network node.
K flag service ack 1 ‘1’ defines that the NV is using acknowledged service.
L flag polled 0 ‘1’ defines that the NV is using the polled attribute
M flag sync 0 ‘1’ defines that the NV is a synchronous NV.
N deviceref 1 This field is a numeric reference to a device description.
If it is the first occurrence of this reference in the file,
the columns defined below must be filled in. Otherwise,
they can be left out.
O programID 9000A44850060402 The program ID string of the network device.
P neuronID 80000000C8C8 The NID of the network device.
Q subnet 2 The subnet address of the network device. Use ‘0’ if the
device has no subnet address information.
R node 3 The node address of the network device. Use ‘0’ if the
device has no node address information.
S location str 0 The location string of the network device. Use ‘0’ if no
information is available.
T devicename DDC The device name of the network device. Leave this field
blank if this information is not available.
U node self-doc &3.2@0,2 Self-documentation string of the device (special
characters are escaped)
V NV length 2 NV length in bytes
W NV self-doc @0|4 NV self-documentation string (special characters are
escaped)
X allocation 1 Define, how this NV shall be allocated: external=1
(default) /static=2/file=3
Table 9: CSV Columns of the NV Import File
7.2.2 Node Object
The L-Gate provides a node object conforming to the LONMARK guidelines. A diagram of
the node object is depicted in Figure 112.
