L-Gate User Manual 65 LOYTEC
Version 3.2 LOYTEC electronics GmbH
6.2.1 Folder List
At the left is a list of folders which is used to sort the available data objects by their
category. There are a number of predefined folders available:
• Imported: This folder has a number of sub-folders for different import methods:
o BACnet Network Scan: This folder is used to display data points retrieved
by an online scan of the BACnet network.
o BACnet EDE File: This folder is used to display data points imported from
an EDE file.
o CEA-709 CSV File: This folder is used to display data points imported from
CSV files.
o CEA-709 LNS Scan: This folder is used to hold data retrieved from a
network database scan.
o CEA709 Network Scan: This folder holds NVs scanned online from an
attached CEA-709 network.
Data objects in the import folder are not stored on the device when the project is
downloaded. They represent data objects which are available on remote devices
and are shown here as templates to create suitable data objects for use on the
device by selecting the Use on Device option.
• Filter Templates: This folder contains the created data point templates. They contain a
set of properties, which are applied to data points, when they are created on the device.
There is a sub-folder for filter templates specific to different technologies, e.g. CEA-
709.
• L-Gate: This is the device folder of the L-Gate. It contains all the necessary data
points which constitute to the L-Gate’s port interface definition. These data points are
created on the L-Gate when the configuration is downloaded. The three subfolders
represent
o System Registers: This folder contains system registers, which provide
information on the device itself.
o User Registers: This folder holds user-definable registers. These registers are
not visible on the underlying network and are intended for internal usage.
o CEA-709 Port: This folder contains data points, schedulers, calendars, trend
logs, statistics, and remote data points of the CEA-709 network technology.
See Section 6.2.2.
o BACnet Port: This folder contains data points, schedulers, calendars, trend
logs, statistics, and remote data points of the BACnet network technology.
See Section 6.2.2.
• Global Objects: This top-level folder contains sub-folders that organize specific
application objects that operate on data points.
o E-mail Configuration: This folder contains e-mail templates. An e-mail
template defines the destination address and text body of an e-mail, which is
triggered by data points and may contain data point values or file attachments.
To create an e-mail template, select the folder and use the context menu.
o Math Objects Configuration: This folder contains math objects. Math
objects are used to perform a predefined calculation on a number of input data
points and write the result to a defined set of output data points. Each math
object contains one formula. To create a math object, select the folder and use
the context menu.
o Alarm Log Configuration: This folder contains the alarm log objects. Each
alarm log object creates a historical log of alarm transitions of one or more
