L-Gate User Manual 159 LOYTEC
Version 3.2 LOYTEC electronics GmbH
13 Specifications
13.1 LGATE-900
13.1.1 Physical Specifications
Operating Voltage 12-35 VDC or 12-24 VAC ±10%
Power Consumption typ. 3 W
In rush current up to 950 mA @ 24 VAC
Operating Temperature (ambient) 0°C to + 50°C
Storage Temperature 10°C to +85°C
Humidity (non condensing) operating 10 to 90% RH @ 50°C
Humidity (non condensing) storage 90% RH @ 50°C
Enclosure Installation enclosure 6 TE, DIN 43 880
Environmental Protection IP 40 (enclosure); IP 20 (screw terminals)
Installation DIN rail mounting (EN 50 022) or wall
mounting
13.1.2 Resource Limits
Total number of data points 10000
User registers 1000
NVs (static, dynamic) 1000
External NVs 1000
Alias NVs 1000 (both in ECS and legacy mode)
Address table entries 512 (15 in legacy mode)
L
ONMARK calendar objects 1 (25 calendar patterns)
L
ONMARK scheduler objects 100
