L-Gate User Manual 20 LOYTEC
Version 3.2 LOYTEC electronics GmbH
Behavior Description Comment
GREEN flashing fast Traffic
GREEN flashing at 1Hz L-Gate is unconfigured
RED permanent Port damaged
RED flashing fast Traffic with high amount of errors
RED flashing at 1 Hz
(all ports)
Firmware image corrupt
Please upload new firmware.
ORANGE permanent Port disabled e.g. using LSD Tool
ORANGE flashing fast Traffic on port configured as management port e.g. using LSD Tool
Table 2: CEA-709 Activity LED Patterns
3.4.5 Ethernet Link LED
The Ethernet Link LED lights up green whenever an Ethernet cable is plugged-in and a
physical connection with a switch, hub, or PC can be established.
3.4.6 Ethernet Activity LED
The Ethernet Activity LED lights up green for 6 ms whenever a packet is transmitted or
received or when a collision is detected on the network cable.
3.4.7 CN/IP LED
The CNIP LED is a three color LED that indicates different operating states of the L-
Gate’s CEA-852 device.
Green: The CEA-852 device is fully functional and all CEA-852 configuration data
(channel routing info, channel membership list, send list) are up-to-date.
Green flicker: If a valid CEA-709 packet is received or transmitted over the IP channel, the
CNIP LED turns off for 50 ms. Only valid CEA-709 IP packets sent to the IP address of
the L-Gate can be seen. Stale packets or packets not addressed to the L-Gate are not seen.
Yellow: The CEA-852 device is functional but some configuration data is not up-to-date
(device cannot contact configuration server but has configuration data saved in Flash
memory)
Red: The CEA-852 device is non-functional because it was rejected from the CEA-852 IP
channel or shut-down itself due to an internal error condition.
Off: The CEA-852 device is non-functional because it has not been started. This can be the
case if the L-Gate uses DHCP and it has not received a valid IP configuration (address)
from the DHCP server.
Flashing Red at 1 Hz: The CEA-852 device is non-functional because it is started but has
not been configured. Please add the device to a CEA-852 IP channel (register in
configuration server).
Flashing green or orange at 1 Hz: The L-Gate’s CEA-709 side of the gateway has not been
commissioned yet. The color indicates the CEA-852 IP channel status as described above.
3.4.8 BACnet/IP LED
The BACnet/IP LED flashes green for 25 ms when BACnet packets are transmitted or
received over the BACnet/IP interface.
