The CSV file must be named “bacclnt.csv” and stored in the directory “/var/lib/bacnet” on
the L-Gate. The file is read when the device boots. If any errors occur they are reported in
“/tmp/bacclnt.err”.
The column format is shown in Table 11. Lines beginning with a hash (‘#’) sign are
comment lines. The example values in Table 11 setup a client mapping named “Lamp
Room 302”, which writes (mapping type 2) the present value of the local object AI,4 to the
remote object AO,1 on the device with the instance number 17801.
Column Field Example Description
A Description Lamp Room 302 User-defined description of this client mapping. Can be
left empty. Don’t use commas or semi-colons in the
text!
B Local Object-Type AI The BACnet object type of the local server object (AI,
AO, AV, BI, BO, BV, MI, MO, MV)
C Local Object
Instance Number
4 The object instance number of the above object.
D Remote Device
Instance
17801 The device object instance number of the remote
BACnet device
E Remote Object-
Type
AO The BACnet object type of the remote server object (AI,
AO, AV, BI, BO, BV, MI, MO, MV)
F Remote Object
Instance Number
1 The object instance number of the above object.
G Map Type 2 Defines the type of the mapping: 0=Poll, 1=COV,
2=Write
H Interval/
Priority
8 Defines the poll interval in seconds for poll mappings
and the COV lifetime in seconds for COV mappings.
For write mappings this defines the write priority
(1..16). Omit this field or set it to ‘-1’ to write w/o
priority.
Table 11: CSV Columns of the BACnet Client Mappings File
7.3.3 EDE Export of BACnet Objects
The BACnet server object configuration of the L-Gate is accessible as a set of CSV files
following the EDE format convention. They can be downloaded via FTP from the directory
‘/data/ede’ on the device. The files are
• lgate.csv: This is the main EDE sheet with the list of BACnet objects.
• lgate-states.csv: This is the state text sheet. For each state text reference in the main
sheet, a line contains the state texts for this multi-state object.
• lgate-types.csv: This is the object types text sheet. The file contains a line for each
object type number. Note, that lines for standard object types can be omitted.
• lgate-units.csv: This is the unit text sheet. The file contains a line for each engineering
unit enumerator value. Note that lines for standard units can be omitted.
