4. Parameters
4-28
Parameter Unit Initial
Details
Applic
ation
mode
Code Name Minimum
Maximum
St-09
Accumulated
overload rate
[%] 0.0
Displays the currently accumulated load factor
against the maximum accumulated load factor as a
percentage.
(Details: Refer to “4.3.4 Torque and Load Display.”)
PST
Accumulated
overload
-300.0 300.0
St-10
Instantaneous
maximum load
factor
[%] 0.0
Displays the instantaneous maximum load factor
against the rated load factor.
 Displays, as a percentage, the maximum
overload between the current time and the start
of control set off when the servo turned on.
(Details: Refer to “4.3.4 Torque and Load Display.”)
PST
Maximum load -300.0 300.0
St-11
Torque limit [%] -
Displays the torque limit value.
 Displays, as a percentage, the maximum torque
that the servo motor can output, against the
rated torque.
(T_LMT contact ON: Analog torque input. T_LMT
contact OFF: [P1-13] and [P1-14] values)
PST
Torque limit -300.0 300.0
St-12
DC link voltage [V] 0.0
Displays the current DC link voltage of the main
power.
 The DC link voltage of the standard drive that
uses 220 [V] is approximately 300 [V].
 The maximum DC link voltage allowed for the
standard drive that uses 220 [V] is 405 [V].
 The overvoltage alarm [AL-41] triggers when the
DC link voltage threshold is exceeded because
there is either too much or too little regenerative
resistance.
 The normal DC link voltage in the regenerative
section is 385 [V] or below.
(Details: Refer to “4.3.4 Torque and Load Display.”)
PST
DC link voltage 0.0 500.0
St-13
Regenerative
overload
[%] 0.0
Displays the regenerative overload rate.
PST
Regeneration
overload
0.0 20.0
St-14
Input contact
status
- -
Displays the input contact status that the servo
recognizes.
(Details: Refer to “4.1.5 External Input Contact Signal
Display.”)
PST
Input Status - -
St-15
Output contact
status
- -
Displays the output contact status that the servo
outputs.
(Details: Refer to “4.1.6 External Input Contact Signal
Display.”)
PST
Output status - -
St-16
Single-turn data
(Single-turn data)
[pulse] 0
Displays the single-turn data of the encoder in
pulses.
PST
Single-turn data 0 2^30
St-17
Single-turn data
(Degrees)
[˚] 0.0
Displays the single-turn data of the encoder in
degrees.
PST
Single-turn data
(Degrees)
0.0 360.0
St-18
Multi-turn data [rev] 0
Displays the multi-turn data of the encoder.
PST
Multi-turn data -32768 32767
