LSIS XDL-L7SA002X

4. Parameters
4-31
Parameter Unit Initial
Details
Applica
tion
mode
Code Name Minimum
Maximum
P0-06
Main power
input mode
- 0b00000
Sets main power input.
DIGIT 1-> 0: Single-phase power
1: 3-phase power input
Caution: Using single-phase power may
lower motor output.
DIGIT2 -> 0: Alarm in case of phase loss
1: Warning in case of phase loss
PST
Power fail mode 0b00000 0b11111
P0-07
RST checking
time
[ms] 20
Sets the time to check main power phase loss.
PST
RST check time 0 5000
P0-08
Displays
parameter
upon start.
- 0
Sets the number for the operation status
parameter that is displayed at the start.
(Details: Refer to “4.4.1 System Parameter
Setting.")
PST
Start up
parameter
0 26
*P0-09
Regenerative
overload
derating
[%] 100
Sets derating factor for checking of regenerative
resistance overload. The overload alarm triggers
quickly when the derating value is set to 100% or
below.
PST
Regeneration
derating
1 200
**P0-10
Regenerative
resistance value
[] 0
Sets the resistance value for regenerative
braking resistance. If set to 0, the default
resistance value of the drive is used.
PST
Regeneration
brake resistor
0 1000
**P0-11
Regenerative
resistance
capacity
[W] 0
Sets the capacity for the current regenerative
resistance. If set to 0, a default resistance
capacity embedded in the drive is used.
PST
Regeneration
brake capacity
0 30000
*P0-12
Overload check
Base load factor
[%] 100
Indicates the load factor for starting
continuous overload checks. If set to 100 or
below, an overload check starts early and the
overload alarm triggers early.
PST
Overload check
base
10 100
P0-13
Continuous
overload
warning level
[%] 50
Indicates the level of continuous overload
warning signal output. Outputs the warning
signal when the percentage value against
alarm trigger load factor is reached.
PST
Overload
Warning Level
10 100
*P0-14
Encoder output
scaling
- 12000
Sets the encoder output pulses per a rotation,
when the servo outputs an encoder output signal
to the outside.
(Details: Refer to “4.4.1 System Parameter
Setting.")
PST
Pulse out per
rotation.
-2^21 2^21
*P0-15
PWM OFF delay
time
[ms] 10
Sets the time to delay until the PWM signal
actually goes off after the servo is turned off.
(Details: Refer to “4.4.1 System Parameter
Setting.")
PST
PWM OFF
delay
0 1000
