Additional pages GMK4100L-1 3 302 710 en 9
16.01.2018
Final drive
Driving menu
Transverse differential locks on/off
When a symbol (1) is selected all transverse differential locks are switched
on or off.
Longitudinal differential lock on/off
(A) – longitudinal differential lock display
(B) – transverse differential lock display
The current status is shown using different
symbols:
Opening: Select symbol (1) and confirm – menu is opened
– To switch on: Select symbol (1) and confirm – symbol is red
– To switch off: Select symbol (1) and confirm – symbol is green
– To switch on: Select symbol (1) and confirm – symbol is red
– To switch off: Select symbol (1) and confirm – symbol is green
1 Green – locks off
2Red – locks on
3 Yellow – intermediate position
4Violet – error
à p. 28
