Sub Monster
The Submonster is a sub-harmonic synthesizer eect which boosts the low frequencies of an audio signal by generating an additional signal an octave below a given
frequency range. The aim of this eect is to add low end to a signal which may have weaker low frequency content or to generally increase the bass frequencies.
The Submonster works particularly well on drum tracks, especially bass drums, and when applied to an overall mix. When placed on individual instruments it can
create a sub-octave doubling eect, which works well when applied to monophonic sounds. The eect has ve tunable bands of sub-octave synthesis, each with
its own gain control. The frequencies on which the bands are centered are controlled using the tune parameter, which controls all ve bands center frequencies to
reduce overlap.
The tune parameter ranges from 20 Hz to 60 Hz which corresponds to the frequency of the lowest generated sub-harmonic band, with each subsequent band having a
minimum and maximum frequency of 1.5x the previous band’s minimum and maximum frequency. This gives a total range of sub-harmonic synthesis between 10 Hz
and 150 Hz.
Item Control Function
1 Input meter 14 LEDs, which show input metering.
2 Tune Control
Adjust the target frequency from 20 Hz to 60 Hz. Harmonics are created by generating an additional
signal an octave below the selected frequency range.
3 Band 1 - 5 Gain Display Shows the amount of added sub-harmonic gain per band.
4 Band 1 - 5 Frequency
Displayed frequency of created sub-harmonic: Band 1 = 10 Hz - 30 Hz, Band 2 = 15 Hz to 45 Hz,
Band 3 = 22.5 Hz to 67.5 Hz, Band 4 = 33.8 Hz to 101.2 Hz, Band 5 = 50.6 Hz to 151.9 Hz.
5 Band 1 - 5 Fader level Set level of the chosen band from -40 dB to 0.00 dB
6 Band 1 - 5 Meters 14 LEDs, which show band level metering.
7 On/O switch Turns the eect on or o.
8 Output meter 14 LEDs, which show input metering.
9 Mix control Adjusts the Wet/Dry blend of the eect when inserted on a channel.
