M Harmonics
This eect adds rich harmonics to signals. From vintage tones to full on fuzz. Choose a blend of 2nd or 3rd harmonics to add depth to drums or other sources. The Drive
control increases the amount of the eect. The colour allows tonal changes to be made. Turning the colour control CCW increases bass information while turning CW
adds more treble detail.
Item Control Function
1 Input meter LED Metering shows input level.
2 Input Meter VU VU Metering shows input level.
3 On/O button Acts as bypass when needed.
4 Output meter Metering shows output level.
5 Input Gain ∞ to 0 dB. Input gain control.
6 Harmonics Turn CCW to add 2nd harmonic content. Turn CW to add 3rd harmonic to the signal.
7 Drive Adding drive adds more of the selected harmonics to the signal. From 10% to 100%.
8 Colour Turn CCW to increase low end content, turn CW to add high end content.
9 Mix control Adjust the wet/dry mix of the band from 0% to 100%.
10 Output Gain ∞ to 0 dB. Output gain control.
