187 HD96-24-CC-TP User Manual
Item Control Function
1 Input meter 14 LEDs, which show input metering.
2 Input Trim control Adjust the trim level into the eect. Range +-12 dB.
3 Freq range (Low/Mid/High) Displays the frequency range of the band.
4 Type selection There are three distortion types. Tube Warmth, Saturation and Tube Distortion.
5 X-Over Low control Sets the low band range, adjustable with a 24 dB per octave crossover lter. 30 Hz to 9 kHz.
6 X-Over High control Sets the high band range, adjustable with a 24 dB per octave crossover lter. 30 Hz to 9 kHz.
7 Post Filt button The Post Filter section can be used for extra control over the extra harmonics created by the distortion.
8 Cab On switch Activates the guitar amp cab simulation.
9 Cab Type selection
A guitar cabinet can be applied to the output, which can add the characteristic timbre of 11 dierent
cabinet types which are: 1 = 8" Tweed. 2 = 4x10" Bass. 3 = 4x10" Custom. 4 = 12" Mid Combo. 5 = 12"
Black. 6 = 12" Brit'60. 7 = 4x12" Brit'96. 8 = 4x12" Std'78". 9 = 4x12" O Axis. 10 = 4x12" Custom. 11
= Rack Amp.
10 Output Trim control Adjust the trim level output of the eect. Range +-12 dB.
11 Output meter 14 LEDs, which show input metering.
12 On/O button On/O control for the distortion.
13 Meter (High/Mid/Low) Displays the amount of compression occurring via LED and tube warmth.
14 Squash (High/Mid/Low) control Controls the amount of compression being applied.
15 Drive (Low/Mid/High) control Adjusts the drive for each band from 1 to 11 (1 louder than 10)
16 Mix (Low/Mid/High) control Adjust the wet/dry mix of the band from 0% to 100%.
17 Trim (High/Mid/Low) control Adjust the level of the band. Range +-12 dB.
18 Mute (Low/Mid/High) button Mutes the selected band.
19 Solo (Low/Mid/High) button Solos the selected band for audition.
To Next Page
