Master Section on the control surface
The MASTER area allows control of the main stereo and mono bus outputs.
Item Control Function
1 Mute button Turns o/mutes main stereo master bus
2 Mute button Turns o/mutes mono bus
3 Meter Master stereo bus LED meter
4 Meter Mono bus LED meter
5 Level control Continuously variable control of stereo master bus
6 Level control Continuously variable control of mono bus
7 C/O
The changeover button switches the master stereo bus rotary to the surface fader directly below.
This overrides any input or output active on the surface in that position.
8 C/O
The changeover button switches the mono bus rotary to the surface fader directly below. This
overrides any input or output active on the surface in that position.
