Midas HD96-24-CC-TP User Manual

305 HD96-24-CC-TP User Manual
Input / Output Characteristics
Surface input impedance 10 kΩ
Non-clip maximum input level +24 dBu
Input gain -22.5 dB to +65 dB
Phantom power +48 V
(switchable per input)
Talk mic impedance 5 kΩ
Talk mic gain +15 dB to +60 dB
Talk mic max level +6 dB
Talkback impendance 20 kΩ
Talkback gain ∞0 to + 10 dB
Talkback max level +21 dBu
Surface output impedance 50 Ω
Surface output gain 0 dB
Surface output max level +21 dBu
Dynamic range 106 dB, 22 Hz to 22 kHz, unweighted
Maximum voltage gain 100 dB inputs to subgroups and
masters, 106 dB inputs to aux
and matrix
Crosstalk at 1 kHz -100 dB physically adjacent
input channels
Crosstalk at 10 kHz -90 dB physically adjacent
input channels
Fader / pan cut o at 1 kHz -100 dB
Fader / pan cut o at 10 kHz -100 dB
Headphones output impedance 10 Ω
Headphones maximum +21 dBu
output level
Displays
Display screen 21" LCD high brightness
1920 x 1080 px, captive touchscreen,
up to 10 simultaneous touches
LCD info displays 41 x full colour LCD info displays,
24 mm x 24 mm (size), 240 x 240 px
Input meters (quantity 30) 12 segment -35 dBu to +20 dBu
Output meters (quantity 7) 20 segment -36 dBu to +21 dBu
Channel comp meters 5 segment -24 dBu to -1 dBu
(quantity 28)
Channel gate meters 5 segment -34 dBu to
-5 dBu (quantity 28)
Comp meter (quantity 1) 12 segment -23 dBu to -1 dBu
Gate meter (quantity 1) 12 segment -34 dBu to -1 dBu
Controls
100 mm motorized faders 8 + 8 + 8 + 4
Touch-sensitive rotary controls 66
Custom controls
Fully assignable rotary controls 28 + 8
Fully assignable backlit buttons 28 + 8 + 12
Headphone controls A and B, min to max
Talk Talk gain min to max
Wi-Fi
Antenna Internal dual-band
IEEE 802.11 a/b/g/n Supports a / b / g / n devices
Frequency range 2412-2462 MHz / 5.15–5.850 GHz
operation dependent on region
Max output power 20 dBm (using 5 GHz range)
Bluetooth
Version 4.0 EDR and LE
Power 20 dBm
Compatibility Supports GAP, SDN, PAN, SPP, IAP, HFP
1.5, GATT, ATTR, IAP, A2DP, ACRP.
Maximum communcation range 30 m typical
Power
Switch-mode power supply 2 x auto-ranging 100-240 V
(50/60 Hz)
Power consumption 2 x 650 W
Current 9 A max
Physical
Operating temperature range 5 °C to 45 °C(41°F – 113°F)
Storage temperature range -20 °C to 60 °C (-4°F – 140°F)
Dimensions(H x W x D) 352 x 1028 x 719 mm
(13.9 x 40.5 x 28.3")
Weight 43.2 kg(95.0 lbs)
