Milestone ultraWAVE 3 - Pressure Vessel

Milestone Srl MA245-003 – ultraWAVE 3 – User Manual
25
Dimensions
• Height (A) : 99 cm
• Height with raised up shield : 138 cm
• Width (B) : 55 cm
• Depth (C) : 63 cm
Weight
approx. 130kg
depending on system configuration
Recommended Service Frequency
1 x yearly or after max. 600 runs
Temperature range
5°-40°C
Maximum altitude
2000m
Maximum loudness (with Compressor)
85 dB
Pressure Vessel
Material
Stainless steel
Capacity
950 ml
incl. fittings
Max. Allowed pressure (rupture pressure disk)
199 bar
Maximum Operating Pressure
190 bar
Max. Allowed Wall Temperature
90°C
A
B
C
