Do not use any PTFE or sticking band for tightening
After each digestion run and pressure release, the internal valve of the ultraWAVE 3, purges some gas
from cylinder (12 - 15 seconds) to remove residual fumes from the reactor.
Pneumatic Booster (Optional)
The Pneumatic booster allows to load the pressure in the reactor in case the gas line inlet is lower than
50 bar.
Therefore, this configuration is useful for all laboratories that do not have the possibility of keeping a
cylinder near the instrument, or laboratories that do not have a high-pressure line (at least 50 bar)
available to which they can connect the instrument directly or with the automatic gas loading module.
Pneumatic booster can be connected to a gas cylinder or a Nitrogen generator unit.
Pneumatic booster connected to Nitrogen / Argon cylinder
Gas
source
Standard
pressure
regulator
Connection
with
booster
Air
compressor
Pneumatic
Booster
ultraWAVE
3 unit
Nitrogen /
Argon
cylinder
Standard
pressure
regulator (0-10
bar)
Pneumatic
booster requires
4-10bar pressure
Polymer
tube: 2m
length
6mm (ID) –
8mm (OD)
Air compressor
with pressure
regulator
directly
connected to
the pneumatic
booste.
To operate, the
booster requires
an air pressure
between 3 - 6
bar
Pneumatic booster
to load pressure
into the ultraWAVE
reactor
Microwave
unit
Not
included
in the
ultraWAVE
3
package.
Not included in
the ultraWAVE 3
package
P/N SL0050
Included in
the
ultraWAVE 3
package
Air compressor
and pressure
regulator of air
are not included
in the
ultraWAVE 3
package
P/N GSB00100
Optional, can be
ordered separately
