Milestone ultraWAVE 3 - Page 42

Milestone Srl MA245-003 – ultraWAVE 3 – User Manual
40
Loosen of screw/valve
• Connect the connection for the filter (P/N 65793) to the high-pressure regulator (E)
Connection of pressure reducer to ultraWAVE 3
• Connect the filter to the high-pressure hose with a 17 mm fork wrench
The arrows indicate the flow direction.
Flow direction on the buffer
• Connect the other end of the hose to the ultraWAVE 3; tighten with a 17 mm fork wrench while
holding it firm during turning.
Back side of the unit
P/N 65793
