Milestone Srl MA245-003 – ultraWAVE 3 – User Manual
26
Cooling water
Use only deionised water or a mixture of 50% deionised water and 50% tap water for cooling, at a
temperature of 8°C-15°C and a pressure of 2-4 bar.
Instrument Sensors
Sensor name
Description
Function
T1
Infrared temperature sensor
Internal temperature of the
vessel
T2
Integrated-circuit temperature sensor LM35
Vessel Wall temperature sensor
T mag
Integrated-circuit temperature sensor LM35
Magnetron temperature sensor
Temperature
Switch
Set temperature: 90 °C
Temperature switch for reactor
wall overheating
Internal Pressure
Pressure Gauge
Measuring pressure: 0-250 bar
Internal Pressure
Pressure Transducer
Measuring pressure: 0-200 bar
Proximity sensors for lifting system
Sensor name
Description
Function
S1
Inductive Sensor
Safety Shield closed sensor
S2
Mechanical Sensor
Automatic Pressure Release valve
closed
S3
Inductive Sensor
Cover lifting support on front
position
S4
Inductive Sensor
Left side clamp fully opened
S4B
Inductive Sensor
Right side clamp fully opened
S5
Inductive Sensor
Left side clamp closed
S5B
Mechanical Sensor
Clamps locking pin unlocked
S6
Mechanical Sensor
Reactor cover fully closed
