Milestone Srl MA245-001 – ultraWAVE 3 – User Manual
77
Oil level should be between the marks.
It should not be over or under.
Should the oil level be under the mark, oil must be
re-filled (dose it carefully adding only small quantities
at a time).
Pull out the stick and use a small funnel to refill.
Proceed slowly. Check the oil level under constant
measuring conditions.
Condensate generated during operation is
gathered in the intermediate separator and
filtering system. Condensate is discharged
both over the oil separator and the
condensate drain.
Condensate should be
discharged at least once daily.
(Open both caps).
Open the caps to discharge and let the condensate run off. Condensate is collected in a suitable tank and
disposed of at a later stage.
