Milestone Srl MA245-001 – ultraWAVE 3 – User Manual
97
To open the files, you must have the correct rack
configuration. If the configuration of the file does
not match the one in the software, it will not be
possible to open the file.
Delete a run file
Select the run file to delete from the list.
Keep the file selected until the menu opens.
From the menu select delete.
Graphical representation
The individual graphs can be displayed or hidden from the screen by pressing the corresponding button.
T1, RED
The curve (setpoint curve and measured curve)
for the easyTEMP sensor, internal temperature.
T2, ORANGE
The curve (setpoint curve and measured curve)
for the external temperature.
This is the temperature of the external side of
stainless-steel reactor
