Milestone ultraWAVE 3 - ULTRAWAVE 3 OPERATION; Sample Handling and Digestion Workflow

Milestone Srl MA245-003 – ultraWAVE 3 – User Manual
51
To access the System window, just click on the reactor logo which can be on the home screen or in the
menu, depending on how the software display is configured.
The pressure vessel can only be opened when the system is under no-pressure conditions.
Clamps must be opened and completely turned backwards.
Press the UP icon to lift the front cover
Press the lock to lower the pin that close the clamps.
Untight the locking screw and open both clamps of
reactor
