Milestone Srl MA245-001 – ultraWAVE 3 – User Manual

Turn on or off the fume extraction

List of recently opened methods

Audit Trail

Add additional information on samples and chemicals used for the

digestion

PDF files of the digestion runs

User manual

Video tutorials to operate with the unit

Supervision of the instrument's activity

Information related to the unit

Main Page
