8 Settings Related to Output Control
105
1. Press once to display .
2. Press .
Function mode is activated, and the display changes to a two-digit numerical value prefixed by
[F-].
3. Using and , change the numerical value to any of , ,
, , , and , then press .
A two-digit number showing the currently set external control input function appears.
Number Function
00 Does not use the external control input function.
01 Designate zero set.
02 Designate zero set clear.
03 Designate hold (level).
04 Designate hold (pulse).
05 Designate PEAK/TRACK.
06 Designate RESET.
07 Designate SEL1.
08 Designate SEL2.
09 Designate CHECK value.
10 Designate comprehensive key lock.
11 Print command (through serial interface), Print command synchronization mode
12 Designate forced termination of multimode.
00
For setting procedures with and , see Section 1.6, "Basic key operation".
4. Using and , set the external control input function, then press .
5. To set the external control input function to other functions, repeat Steps 3 and 4.
6. To set the response time against the external control input, display , then press .
The number showing the currently set response time appears.
Number Response time
0 50 ms
1 20 ms
2 10 ms
3 5 ms
4 2 ms
5 1 ms
0 (50 ms)
The external control input function will be enabled after a signal longer than the set response
time is input.
Default
Default
