A Specifications of CSD-709
133
A.2 Digital Specifications
Main display
(load window)
Display range -99 999 ~ 99 999
Display increment 1 (can be changed to 2, 5, or 10)
Display unit Green 7-segment LED, Character height: 17 mm
Out-of-range display [-OL] appears in case of minus overflow.
[OL] appears in case of plus overflow.
AD overflow display [-OVF] appears in case of minus overflow.
[OVF] appears in case of plus overflow.
Status window SEL.1, SEL.2, CHECK, HOLD, PEAK, MEAS., END, LOCK
Judgment window OUT1, OUT2, OUT3, OUT4
Display times 20 times/s (can be changed to 4, 50, or 100 times/s)
Decimal point display Can be changed to no display, 101, 102, 103, and 104
A.3 Functions of Front Panel Sheet Key Switches
Selects any mode other than Measurement mode, such as Function mode.
Transitions to the simplified numerical value input calibration (by holding down this
key for at least two seconds).
Allows you to move to the next upper digit in the setting target.
Transitions to the simplified zero calibration (by holding down this key for at least two
seconds).
Transitions to the simplified calibration lock mode (by simultaneously holding down
and for at least two seconds).
Increases the numerical value of the setting target by one.
Transitions to the simplified span calibration (by holding down this key for at least
two seconds).
Selects the track value and various peak detection modes (detection of peak,
bottom, peak-bottom, peak-to-peak, maximum, minimum, maximum-minimum
difference, average, or inflection point) (entire section designation mode).
Otherwise, controls the hold section in the section designation mode or time and
section designation mode.
Resets the peak. The display is fixed to [0] while this key is being turned on.
Turns on/off the CHECK value.
Selects [Off], [Hold], [Zero set], [Zero set clear], [Print command], [COMP setting
mode], [CC-Link number], [Confirmation of RS-422/485 ID], or [Forced termination of
multimode].
Registers the setting.
