A Specifications of CSD-709
134
A.4 External Control Function
A.4.1 External control input signal
You can select any of six signals among those listed below.
Off
Zero set
Zero set clear
Hold (pulse)
Print command (serial interface), Print command synchronization mode
Forced termination of multimode
* These functions are enabled once when the pulse input width is 50 ms or longer. (The pulse width
can be changed to 1, 2, 5, 10, or 20 ms.)
Hold (level)
PEAK/TRACK
RESET
SEL.1
SEL.2
CHECK
Comprehensive key lock
* These functions are enabled while the level that is 50 ms or longer is being input (at the time of
the short-circuit.) (The level width can be changed to 1, 2, 5, 10, or 20 ms.)
A.4.2 External control output signal
You can select any of six signals among those listed below.
Off
Hold
PEAK (turned on interlocking with the status display)
MEAS. (turned on interlocking with the status display)
END (turned on interlocking with the status display)
MULTI (turned on in multimode)
EXCUTE (turned on during measurement in multimode)
OK (turned on when [lower limit < current load < upper limit] is met)
NG (turned on under any condition, except for OK condition)
Upper/lower limit (turned on under [upper limit ≤ current load] and [current load ≤ lower limit])
S0
S1
S2
ERROR
Over error (±OL, ±OVF)
Zero set response (turned off after elapse of 500 ms)
RUN (level)
RUN (toggle)
